Double Head Faceting Machines

Technical Specification:

• Type of Main Centre: Fixed
• Type of Head: Revolving
• No. of axis: 2 (Z – Vertical Z-1 Vertical for Depth)
• Vertical Z axis Movement: Screw
• Vertical Z-1 axis for depth: 5.5 mm
• Horizontal Spindle Motor: 0.25 HP / 2800 RPM
• Horizontal Spindle Speed: 5600 RPM
• Vertical Spindle Motor: 0.25 HP / 2800 RPM
• Vertical Spindle Speed: 6500 RPM
• Zigzag Attachment Motor: 0.13 HP / 6000 RPM PMDC Geared
• Net weight: 230 kg
• Gross weight: 260 kg
